To start this process smoothly:
- Send us a drawing: It can be hand-drawn or in CAD format, whichever you prefer.
- Provide us with information about your project: material grade, quantity, length, surface finish, specific testing requirements, required dimensional tolerances, and any other relevant details.
- Unit B, 9/F, Worldwide Centre, 123 Tung Chau Street, Tai Kok Tsui Kowloon.HongKong
- T: +852-92992995
- E: sales@peakkong.com
+
- Standard: EN 10365:2017
- Technology: ISO 15614-11 or ISO 15614-14
- Fabrication Craftsmanship: ASTM A1069, EN 13919
- Steel grade: S275J0, S355J0, S460J0, S460M, S460ML, S690QL
- Tolerance: BS 4-1:2005, DIN 1026-2
- Certificate: According to EN10204-2.2 or 3.1B
| Description | Execution | kg/m | h /mm | b /mm | s /mm | t /mm | r /mm |
|---|---|---|---|---|---|---|---|
| HEM 100 | Laser | 41.8 | 120.0 | 106.0 | 12.0 | 20.0 | 12.0 |
| HEM 120 | Laser | 52.1 | 140.0 | 126.0 | 12.5 | 21.0 | 12.0 |
| HEM 140 | Laser | 63.3 | 160.0 | 146.0 | 13.0 | 22.0 | 12.0 |
| HEM 160 | Laser | 76.2 | 180.0 | 166.0 | 14.0 | 23.0 | 15.0 |
| HEM 180 | Laser | 88.7 | 200.0 | 186.0 | 14.5 | 24.0 | 15.0 |
| HEM 200 | Laser | 102.8 | 220.0 | 206.0 | 15.0 | 25.0 | 18.0 |
| HEM 220 | Laser | 117.0 | 240.0 | 226.0 | 15.5 | 26.0 | 18.0 |
| HEM 240 | Laser | 157.0 | 270.0 | 248.0 | 18.0 | 32.0 | 21.0 |
| HEM 260 | Laser | 172.7 | 290.0 | 268.0 | 18.0 | 32.5 | 24.0 |
| HEM 280 | Laser | 188.4 | 310.0 | 288.0 | 18.5 | 33.0 | 24.0 |
| HEM 300 | Laser | 237.9 | 340.0 | 310.0 | 21.0 | 39.0 | 27.0 |
| HEM 320 | Laser | 244.9 | 359.0 | 309.0 | 21.0 | 40.0 | 27.0 |
| HEM 340 | Laser | 248.1 | 377.0 | 309.0 | 21.0 | 40.0 | 27.0 |
| HEM 360 | Laser | 250.4 | 395.0 | 308.0 | 21.0 | 40.0 | 27.0 |
| HEM 400 | Laser | 255.9 | 432.0 | 307.0 | 21.0 | 40.0 | 27.0 |
| HEM 450 | Laser | 263.0 | 478.0 | 307.0 | 21.0 | 40.0 | 27.0 |
| HEM 500 | Laser | 270.0 | 524.0 | 306.0 | 21.0 | 40.0 | 27.0 |
| HEM 550 | Laser | 277.9 | 572.0 | 306.0 | 21.0 | 40.0 | 27.0 |
| HEM 600 | Laser | 285.7 | 620.0 | 305.0 | 21.0 | 40.0 | 27.0 |
| HEM 650 | Laser | 293.6 | 668.0 | 305.0 | 21.0 | 40.0 | 27.0 |
| HEM 700 | Laser | 300.7 | 716.0 | 304.0 | 21.0 | 40.0 | 27.0 |
| HEM 800 | Laser | 317.1 | 814.0 | 303.0 | 21.0 | 40.0 | 30.0 |
| HEM 900 | Laser | 332.8 | 910.0 | 302.0 | 21.0 | 40.0 | 30.0 |
| HEM 1000 | Laser | 348.5 | 1008.0 | 302.0 | 21.0 | 40.0 | 30.0 |
PeakKong Special Steel applies Peakkong delivery conditions during the delivery process, and adds that both parties will comply with applicable legal and regulatory requirements and will not engage in any unethical business practices.
The products produced by PeakKong Special Steel.Wide flange beams HEM The technical delivery conditions of our products meet the respective requirements. Dimensions and tolerances are defined according to the relevant steel material standards. Engineering work complies with the respective standards.
Wide flange beams HEM Equipped with strapping tags and Peakkong Special Steel product tags to achieve comprehensive traceability and identification. According to the corresponding steel standards, corresponding material certificates will be provided.
